Control Valve Body Assembly
WARNING: This page is about a different variant/trim than selected.
| Callout | Component Name |
|---|---|
| 400 | Pressure Regulator Valve Bore Plug Retainer |
| 401 | Pressure Regulator Valve Bore Plug |
| 402 | Pressure Regulator Valve |
| 403 | Pressure Regulator Valve Spring |
| 404 | Lube Regulator Valve Spring |
| 405 | Lube Regulator Valve |
| 406 | Lube Regulator Valve Bore Plug |
| 407 | Lube Regulator Valve Bore Plug Retainer |
| 408 | Variable Low Clutch Accumulator Piston Spring Retainer |
| 409 | Variable Low Clutch Accumulator Piston Spring |
| 410 | Variable Low Clutch Accumulator Piston |
| 411 | Automatic Transmission Torque Dampener Bypass Clutch Valve Bore Plug Retainer |
| 412 | Automatic Transmission Torque Dampener Bypass Clutch Spring |
| 413 | Variable Low Clutch Valve |
| 414 | Line Pressure Control Solenoid Valve Accumulator Piston |
| 415 | Line Pressure Control Solenoid Valve Accumulator Piston Spring |
| 416 | Control Valve Body |
| 417 | Automatic Transmission Torque Dampener Bypass Clutch Valve |
| 418 | Variable Low Clutch Regulator Valve Spring |
| 419 | Variable Low Clutch Regulator Valve Bore Plug Retainer |
| 420 | Variable High Clutch Valve |
| 421 | Variable Low Clutch Regulator Valve Spring |
| 422 | Variable Low Clutch Regulator Valve Bore Plug Retainer |
| 423 | Variable High Clutch Dam Feed Regulator Valve |
| 424 | Variable High Clutch Dam Feed Regulator Valve Spring |
| 425 | Variable High Clutch Dam Feed Regulator Valve Bore Plug Retainer |
| 426 | Line Pressure Control Solenoid Valve Retainer |
| 427 | Line Pressure Control Solenoid Valve |
| 428 | Pressure Relief Ball Valve Spring Pin |
| 429 | Pressure Relief Ball Valve Spring |
| 430 | Pressure Relief Ball Valve |
