Diesel Fuel Separator Installation

WARNING: This page is about a different variant/trim than selected.
  1. Install the diesel fuel separator (2).
    Fig 1: Diesel Fuel Separator
    GM2189815Courtesy of GENERAL MOTORS COMPANY
  2. Install the exhaust pressure sensor bracket (1).
  3. Install the 2 exhaust pressure sensor bracket bolt (3) and tighten to 9 N.m (80 lb in).
    CAUTION: Refer to Fastener Caution .
