Driver Information Display Replacement (UAG)

Fig 1: Driver Information Display (UAG)
GM2566131Courtesy of GENERAL MOTORS COMPANY
Driver Information Display Replacement (UAG)

Callout Component Name
1 Instrument Panel Accessory Trim Plate
Refer to Instrument Panel Accessory Trim Plate Replacement (UAG) .
2 Driver Information Display Assembly

Procedures

  1. Release the four tabs, remove the driver information display.
  2. Refer to Control Module References for programming and set up information.
