Driver Information Display Replacement (SS)
WARNING: This page is about a different car, the 2010 Pontiac G5 and 2010 Chevrolet Cobalt. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 1 | Windshield Garnish Molding Refer to Windshield Garnish Molding Replacement . |
| 2 | Drivers Information Display Screw (Qty: 3)
CAUTION:
Refer to Fastener Caution
.
Tighten: 2.5 N.m (22 lb in) |
| 3 | Drivers Information Display Assembly |
