Rear Side Door Outside Handle Housing Replacement

WARNING: This page is about a different car, the 2016 GMC Acadia, 2016 Chevrolet Traverse, and 2016 Buick Enclave. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Rear Side Door Outside Handle Housing

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedures Remove the interior trim panel. Refer to Rear Side Door Trim Panel Replacement (Enclave)Rear Side Door Trim Panel Replacement (Acadia or Traverse) . Remove the water deflector. Refer to Rear Side Door Water Deflector Replacement . Remove the outside door handle. Refer to Rear Side Door Outside Handle Replacement .
1	Rear Side Door Outside Handle Housing Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 10 N.m (89 lb in)
2	Rear Side Door Lock Bolt (Qty: 2) Tighten 10 N.m (89 lb in)
3	Rear Side Door Outside Handle Housing Procedures Disconnect the lock and handle rods to remove the housing. Release the inside handle cable retainers before removing the door lock. Disconnect the door lock electrical connector.
