Head Up Display Switch Replacement

Fig 1: View Of Head Up Display Components
GM1803421Courtesy of GENERAL MOTORS CORP.
Head Up Display Switch Replacement

Callout Component Name
1 Instrument Panel Cluster Trim Plate
Refer to Instrument Cluster Trim Panel Replacement .
2 Heads Up Display Switch Screw (Qty: 3)

Tighten:  2 N.m (18 lb in)
3 Heads Up Display Switch
