Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the passenger front seat and the driver front seat. Refer to SEAT REPLACEMENT -- BUCKET in Seats.
  2. Remove the center floor console. Refer to CONSOLE REPLACEMENT -- FRONT FLOOR (FULL LENGTH (AUTO TRANS)) or CONSOLE REPLACEMENT -- FRONT FLOOR (FULL LENGTH (ENVOY)) or CONSOLE REPLACEMENT -- FRONT FLOOR (NON-FULL LENGTH) or CONSOLE REPLACEMENT -- FRONT FLOOR (FULL LENGTH (MANUAL TRANS)) in Instrument Panel, Gages and Console.
    Fig 1: Center Floor Console
    G01466984Courtesy of GENERAL MOTORS CORP.
  3. Remove the passenger and driver door sill plates. Refer to DOOR SILL PLATE REPLACEMENT in Interior Trim.
  4. Remove the passenger and driver side kick panels.
  5. Pull the carpet back in order to access the rear floor air outlets.
  6. Remove the passenger seat wiring harness from the right rear floor air outlet.
  7. Remove the rear floor air outlets from the center floor air outlet.
  8. Remove the rear floor air outlets from the vehicle.
