Special Tools

WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 8001 Dial Indicator Set
Courtesy of GENERAL MOTORS CORP.	J 8092 Driver Handle
Courtesy of GENERAL MOTORS CORP.	J 23327 Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 23456 Booster and Clutch Pack Compressor
Courtesy of GENERAL MOTORS CORP.	J 25024-A Servo Piston/Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 28585 Snap Ring Remover
Courtesy of GENERAL MOTORS CORP.	J 35582 Oil Pump Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 35944-440 Cooler Flush Adapter
Courtesy of GENERAL MOTORS CORP.	J 36346 Fascia Retainer Remover
Courtesy of GENERAL MOTORS CORP.	J 41236 Coast Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 41239-1 Cooler Line Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 43068 Axle Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 43907 Connector Test Adapter Kit
Courtesy of GENERAL MOTORS CORP.	J 44809 Output Shaft Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 45000 Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 45053 Universal Clamp Press
Courtesy of GENERAL MOTORS CORP.	J 45124 Removal Bridge
Courtesy of GENERAL MOTORS CORP.	J 45159 Holding Fixture
Courtesy of GENERAL MOTORS CORP.	J 45160 Differential Bearing Race Remover
Courtesy of GENERAL MOTORS CORP.	J 45161 Manual Shift Shaft Bearing Replacer
Courtesy of GENERAL MOTORS CORP.	J 45164 Spring Compressor Bridge
Courtesy of GENERAL MOTORS CORP.	J 45165 Differential Torque Cross Bar
Courtesy of GENERAL MOTORS CORP.	J 45166 8" Dial Indicator Extension Rod
Courtesy of GENERAL MOTORS CORP.	J 45184 Differential Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 45185 Bore Gage Set
Courtesy of GENERAL MOTORS CORP.	J 45186 Forward and Direct Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 45187 Differential Output Shaft Oil Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 45200 Dial Indicator Set
Courtesy of GENERAL MOTORS CORP.	J 45201 Cooler Line Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 45404 Transmission Indicator Alignment Tool
Courtesy of GENERAL MOTORS CORP.	J 45542 Transmission Line Pressure Adapter
Courtesy of GENERAL MOTORS CORP.	J 47599 Anchor Bolt Socket
Courtesy of GENERAL MOTORS CORP.	J 47687 Rotational Torque Adapter
Courtesy of GENERAL MOTORS CORP.	SA 9127E Gage Bar Set
Courtesy of GENERAL MOTORS CORP.	SA 9165T Oil Cooler Line Flusher
