Removal Procedure

WARNING: This page is about a different car, the 2022 Cadillac CT5. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and support the vehicle. Lifting and Jacking the Vehicle
  2. Underbody Front Air Deflector - Left Side - Remove - Underbody Front Air Deflector Replacement - Left Side
  3. Underbody Front Air Deflector - Right Side - Remove - Underbody Front Air Deflector Replacement - Right Side
  4. GM5652069Courtesy of GENERAL MOTORS COMPANY

    Underbody Rear Air Deflector Bolt (1) - Remove [2x]

  5. GM5334659Courtesy of GENERAL MOTORS COMPANY

    Floor Panel Tunnel Panel Front Brace Bolt (1) - Remove [8x]

  6. Floor Panel Tunnel Panel Front Brace (2) - Remove
