Rear End Spoiler Retainer Cover Replacement (Liftgate)

Fig 1: Rear End Spoiler Retainer Cover (Liftgate)

GM3751591

Courtesy of GENERAL MOTORS COMPANY

Callout

Component Name

Preliminary Procedure

Remove the rear window wiper arm. Refer to Rear Window Wiper Arm Replacement (Chevrolet/GMC)Rear Window Wiper Arm Replacement (Cadillac) .
Remove the liftgate upper trim finish panel. Refer to Liftgate Upper Trim Finish Panel Replacement

1

Rear End Spoiler Retainer Cover Nut

CAUTION:

Refer to Fastener Caution .

Tighten
9 N.m (80 lb in)

2

Rear End Spoiler Retainer Cover

Procedure

From the top edge and with a trim type release tool release the 4 retainers.
Carefully pull back to clear the rear window wiper motor shaft and remove from vehicle.
