Driver Information Display Replacement (Cadillac With IOB)

Fig 1: Driver Information Display (Cadillac With IOB)
GM3648286Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Remove the instrument panel upper trim panel bracket. Refer to Instrument Panel Upper Trim Panel Bracket Replacement (Cadillac) .
1 Radio Control Fasteners (Qty: 4)
CAUTION:

Refer to Fastener Caution .


Tighten
2.5 N.m (22 lb in)
2 Instrument Panel Upper Trim Panel Bracket (Qty: 2)
3 Digital Information Display

Procedure

  1. Transfer necessary components.
  2. Refer to Control Module References for programming and setup information.
