Automatic Transmission Control Indicator Replacement

Fig 1: Automatic Transmission Control Indicator
GM3417086Courtesy of GENERAL MOTORS COMPANY
Callout Component Name

Preliminary Procedure

  1. Remove the left front floor console. Refer to Front Floor Console Replacement .
  2. Remove the front floor console compartment. Refer to Front Floor Console Compartment Replacement .
  3. Remove the front floor rear console side trim panel - left side. Refer to Front Floor Rear Console Side Trim Panel Replacement - Left Side .
1 Automatic Transmission Control Indicator Assembly

Procedure

  1. Use a flat-bladed plastic trim tool in order to release the retainer clips securing the automatic transmission control indicator assembly.
  2. Disconnect the electrical connector.
