Front Seat Adjuster Replacement

Fig 1: View Of Front Seat Adjuster & Fasteners
GM2229173Courtesy of GENERAL MOTORS COMPANY
Front Seat Adjuster Replacement

Callout Component Name

Preliminary Procedure

  1. Remove the driver or passenger seat adjuster memory module. Refer to Driver or Passenger Seat Adjuster Memory Module Replacement (Without UFL) , Driver or Passenger Seat Adjuster Memory Module Replacement (With UFL)
  2. Remove the driver or passenger seat adjuster finish cover. Refer to Driver or Passenger Seat Outer Adjuster Finish Cover Replacement
  3. Remove the driver or passenger seat cushion front cover. Refer to Driver or Passenger Seat Cushion Front Cover Replacement
1 Driver or Passenger Seat Adjuster Fastener (Qty: 4)
CAUTION:

Refer to Fastener Caution


Tighten
5 N.m (44 lb in)
2 Driver or Passenger Seat Adjuster
