Instrument Panel Accessory Bracket Replacement

Fig 1: Instrument Panel Accessory Bracket
GM3587372Courtesy of GENERAL MOTORS COMPANY
Instrument Panel Accessory Bracket Replacement

Callout Component Name
Preliminary Procedure
Remove the instrument panel center air outlet. Refer to Instrument Panel Center Air Outlet Replacement .
1 Instrument Panel Accessory Bracket Bolt (Qty: 5)
CAUTION:

Refer to Fastener Caution .


Tighten
2.5 (22 lb in)
2 Instrument Panel Accessory Bracket

Procedure

  1. Disconnect all electrical connectors.
  2. Remove the Radio Control Assembly. Refer to Radio Control Assembly Replacement .
