Removal Procedure

WARNING: This page is about a different variant/trim than selected.
    Fig 1: Removing Crankshaft Oil Seal
    GM1339607Courtesy of GENERAL MOTORS CORP.
  1. Remove the A/C compressor and power steering pump drive belt. Refer to Drive Belt Replacement - Power Steering and Air Conditioning .
  2. Remove the generator and water pump drive belt. Refer to Drive Belt Replacement - Generator and Water Pump .
  3. Remove the crankshaft balancer. Refer to Crankshaft Balancer Removal .
  4. Use a flat-bladed tool in order to remove the crankshaft oil seal.
