Hazard Warning Switch Replacement
Fig 1: Hazard Warning Switch
Courtesy of GENERAL MOTORS COMPANY
Hazard Warning Switch Replacement
Callout
Component Name
Preliminary Procedures
Remove the instrument panel upper center trim panel. Refer to
Instrument Panel Upper Center Trim Panel Replacement
.
Disconnect the electrical connector.
1
Hazard Warning Switch
