Seat Back Recliner Cable Replacement - Front

WARNING: This page is about a different car, the 2006 Pontiac Montana SV6, 2006 Chevrolet Uplander, and 2006 Buick Terraza. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Front Seat Back Recliner Cable

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice in Cautions and Notices. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .Preliminary Procedure: Remove the front bucket seat. Refer to Seat Replacement - Front Bucket .
1	Handle, Seat Recliner Refer to Seat Back Recliner Handle Replacement - Front .
2	Plug, Seat Recliner Handle
3	Cover, Seat Outer Adjuster Refer to Seat Adjuster Track Cover Replacement - Front .
4	Cover, Seat Outer Adjuster Refer to Seat Adjuster Track Cover Replacement - Front .
5	Bolt, Power Seat Adjuster (Qty: 4) Tighten: 45 N.m (33 lb ft)
6	Frame Assembly, Seat Cushion
7	Cable Assembly, Seat Back Recliner Tip: Once the seat adjuster is separated from the seat frame the cable can be removed from each side of the seat back recliner assembly.
