Insert top automatic air flap control
- Connect top air flap control (3) with the appropriate connector.
- Feed out air flap control, top (3)
and clip the holder (1)
, left and right into the ball head (2)
.
- Tighten the screws (1)
.TIGHTENING TORQUES SPECIFICATION
Air flap control/brake ventilation duct screw Tightening torque 4 Nm
Follow-up work
- Refer to INSTALLING THE FRONT HOOD SEAL .
- Refer to INSTALLING THE COVER IN THE ENGINE COMPARTMENT AT TOP LEFT and INSTALL THE COVER IN THE ENGINE COMPARTMENT ON THE TOP RIGHT .
- Refer to INSTALLING FRONT BUMPER COVER .
- Refer to PARTIALLY INSTALLING THE FRONT SECTION OF THE FRONT WHEEL ARCH COVER ON THE LEFT AND RIGHT .
- Refer to PARTIALLY INSTALLING THE LEFT FRONT AND RIGHT WHEEL ARCH TRIM .
- Refer to INSTALLING FRONT ORNAMENTAL GRILLE .
