Installing the tailgate trim panel

• Check the clips (1)  tailgate trim panel (2)  for damage and replace if necessary.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Position tailgate trim panel (1)  and clip in with clips (2)  .

Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up work

• Refer to INSTALLING BOTH TRIM PIECES FOR THE REAR WINDOW FRAME .
• Refer to INSTALLING THE TOP TRIM FOR THE REAR WINDOW FRAME .
• Refer to INSTALLING THE REAR STORAGE SHELF .
• Refer to INSTALLING THE TRUNK LID LIGHT .
• Refer to INSTALLING THE POWER TAILGATE SWITCH .
