Remove right luggage compartment wheel arch trim panel

Preliminary work

• Refer to REMOVING THE CARGO AREA FLOOR COVERING .
• Refer to REMOVING TRUNK COMPARTMENT LIGHT .
• Refer to REMOVING THE LOADING EDGE TRIM .

Removing mounted parts of luggage compartment wheel arch trim panel

• Unclip covers (1)  of lashing eyes (2)  .
• Release screws (3)  of lashing eyes (2)  .
• Open expanding rivet (4)  of bag hook.

  Courtesy of BMW OF NORTH AMERICA, INC.

• Loosen the expanding rivet (1)  .
• Swivel the lower luggage compartment wheel arch trim panel (2)  inwards and remove it.

  Courtesy of BMW OF NORTH AMERICA, INC.
