51 12 Bumper, Rear
>>
51 12 315 Removing and installing/replacing the rear diffuser
>>
Installing the rear diffuser
Installing the rear diffuser
Install the diffuser
(2)
.
Tighten down screws
(1)
.
Courtesy of BMW OF NORTH AMERICA, INC.
TIGHTENING TORQUE SPECIFICATION
Rear diffuser
screw
Tightening torque
3 Nm
