51 45 031 Replacing instrument panel trim

Remove left fresh air nozzle. See 64 22 135 REMOVING AND INSTALLING / REPLACING LEFT FRESH-AIR GRILL

Remove panel for instrument panel. See 51 45 030 Removing and installing instrument panel trim

Unfasten screws (1) and remove bracket (2).

Convertible only:

Stick sketch below to new instrument panel; this is included with the replacement instrument panel.

Cut out instrument panel at bottom in accordance with sketch.

Fig 1: Removing Bracket

Courtesy of BMW OF NORTH AMERICA, INC.

Detach retainers (1) and remove cover (2) for steering column paneling.

Fig 2: Removing Steering Column Paneling Cover

Courtesy of BMW OF NORTH AMERICA, INC.

If necessary, release screw (1) and detach air duct (2) on left/right.

Fig 3: Detaching Air Duct

Courtesy of BMW OF NORTH AMERICA, INC.

Lift fresh air grill (1) above catches (2) and press out.

Fig 4: Removing Air Grill

Courtesy of BMW OF NORTH AMERICA, INC.

Remove metal nuts (1) from tunnel (2) of instrument panel.

Fig 5: Removing Metal Nuts From Tunnel Of Instrument Panel

Courtesy of BMW OF NORTH AMERICA, INC.

Passenger side:

Remove retainers (1) and (2).

Remove plastic nuts (3) and metal nuts (4).

Fig 6: Removing Retainers, Plastic & Metal Nuts (Passenger Side)

Courtesy of BMW OF NORTH AMERICA, INC.

Driver's side:

Remove clips (1).

Fig 7: Removing Clips (Driver'S Side)

Courtesy of BMW OF NORTH AMERICA, INC.

Driver's side:

Remove metal nuts (1) and plastic nuts (2).

Fig 8: Removing Metal & Plastic Nuts (Driver'S Side)

Courtesy of BMW OF NORTH AMERICA, INC.

Driver's side:

Remove metal nuts (1) and plastic nuts (2).

Fig 9: Removing Metal & Plastic Nuts (Driver'S Side)

Courtesy of BMW OF NORTH AMERICA, INC.
