13 71 150 Removing clean air pipe (N47 D16/20 K/U/O/T 1)

Necessary preliminary tasks:

Press down locking hook and detach hose (1) for engine ventilation.

With the heating element installed, unlock connector from heating element and pull off.

Release screw (2).

Tightening torque: 13 71 2AZ .

Release clamp (3) on exhaust turbocharger and detach clean air pipe (4), feed out and remove upwards.

Fig 1: Identifying Exhaust Turbocharger Clamp And Screw

Courtesy of BMW OF NORTH AMERICA, INC.

Assemble engine.
