65 77 735 Removing and installing/replacing central sensor

WARNING: This page does not describe the selected car, but rather 21 other vehicles, including the 2017 BMW 550i GT xDrive, 2017 BMW 535i GT xDrive, 2017 BMW 535i GT, 2016 BMW 550i GT xDrive, and 2016 BMW 535i GT xDrive. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Note AIRBAG SAFETY INSTRUCTIONS !
Incorrect handling can activate airbag deployment and cause injury.

Necessary preliminary tasks:

Disconnect BATTERY EARTH CABLE
Remove CENTER CONSOLE SUPPORT

Unscrew nuts (1).

Remove holder (2) from center console wiring harness (3).

Fig 1: Identifying Nuts, Holder, And Center Console Wiring Harness

Courtesy of BMW OF NORTH AMERICA, INC.

Unscrew nuts (1).

Tightening torque 65 77 5AZ .

Remove sensor (2).

Unlock plug connection (3) and disconnect.

Installation:

Make sure sensor is mounted without play.

Fig 2: Identifying Sensor, Nuts And Plug Connection

Courtesy of BMW OF NORTH AMERICA, INC.
