66 53 020 Removing and installing (replacing) reversing camera

WARNING: This page is about a different car, the 2013 BMW 550i GT, 2012 BMW 550i GT, 2011 BMW 550i GT, and 2010 BMW 550i GT. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Read and comply with NOTES on protection against electrostatic damage (ESD protection).

Necessary preliminary tasks

Remove HANDLE .

Release screws (1).

Remove cover cap (2).

Fig 1: Identifying Reversing Camera Cover Cap And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Remove rear view camera (1) in direction of arrow from retaining fixture (2).

Replacement:

Remove protective film from lens of reversing camera (1).

Fig 2: Removing Protective Film From Lens Of Reversing Camera

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Seal (1) on rear view camera (2) must not be damaged.

Fig 3: Identifying Rear View Camera And Seal

Courtesy of BMW OF NORTH AMERICA, INC.

After installation:

Calibrate REVERSING CAMERA .

Replacement

Carry out VEHICLE PROGRAMMING/ENCODING .
