64 22 165 Removing and installing/replacing centre fresh air grille

WARNING: This page is about a different car, the 2013 BMW 550i GT, 2012 BMW 550i GT, 2011 BMW 550i GT, and 2010 BMW 550i GT. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks

F01, F02, F03, F06, F12, F13:

Remove decorative strip on dashboard in middle

F07, F10, F11, F18:

Remove DECORATIVE STRIP ON DASHBOARD ON RIGHT .

IMPORTANT: Proceed with care so as to avoid damaging the fresh air grille.

NOTE: Picture for example purposes only!

Replacement

Release screws at marked points at top and bottom.

Remove centre fresh air grille (1).

Fig 1: Locating Centre Fresh Air Grille

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement

Modify SWITCH FOR HAZARD WARNING SYSTEM/CENTRAL LOCKING .
