64 11 395 Removing and installing/replacing control panel for rear cabin A/C system

WARNING: This page is about a different car, the 2013 BMW 550i GT, 2012 BMW 550i GT, 2011 BMW 550i GT, and 2010 BMW 550i GT. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks

Remove REAR CENTRE CONSOLE TRIM .

Following operations relate exclusively to replacement.

NOTE: Example graphic on the F01.

Unlock catches (1).

Press out control panel of rear cabin A/C system (3) downwards and remove from centre console trim.

Installation:

Catches (1) and (2) must perceptibly snap into corresponding guides.

Fig 1: Identifying Rear Cabin A/C System And Catches

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement

Modify FAN MOTOR .
Carry out VEHICLE PROGRAMMING AND ENCODING .
