61 12 200 Replacing wiring harness in left or right front door

WARNING: This page is about a different car, the 2013 BMW 550i GT, 2012 BMW 550i GT, 2011 BMW 550i GT, and 2010 BMW 550i GT. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Read and comply with notes on HANDLING WIRING HARNESSES and cables.

Necessary preliminary tasks

Close front side window completely
Disconnect BATTERY GROUND LEAD .
Remove SOUND INSULATION IN FRONT DOOR .
Remove LEFT-HAND OUTER DOOR HANDLE ON FRONT DOOR .

Unlock plug connections (1) and disconnect.

If necessary, unlock and disconnect Soft Close plug connection.

Unclip door wiring harness (2) at points (3).

Feed out door wiring harness (2).

Installation note:

Make sure door wiring harness (2) is correctly laid.

Fig 1: Identifying Door Plug Connections And Wiring Harness

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Front side panel shown removed for purposes of clarity.

Release screw (1), fold door wiring harness connector on A-pillar (2) downwards slightly and remove.

Unlock plug connection behind and disconnect.

Pull rubber grommet (3) in direction of arrow out of front door (4).

Feed out door wiring harness towards front to A-pillar and remove.

Fig 2: Pulling Rubber Grommet Out Of Front Door
