22 11 001 Replacing Right Engine Mount (N54)

WARNING: This page is about a different car, the 2010 BMW X6, 2009 BMW X6, and 2008 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove right engine support arm . See 22 11 100 REPLACING RIGHT ENGINE SUPPORT ARM (N54) .

Detach vacuum hose (1) from engine mount.

Fig 1: Identifying Vacuum Hose

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1) and remove engine mount (2).

Tightening torque. See 22 11 1AZ in 22 11 ENGINE SUSPENSION .

Fig 2: Identifying Engine Mount And Screw

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Holes (1) in engine mount must point to middle of vehicle.

Fig 3: Identifying Engine Mount Holes

Courtesy of BMW OF NORTH AMERICA, INC.
