11 61 068 Removing and installing/replacing right intake plenum (N63)

WARNING: This page does not describe the selected car, but rather 23 other vehicles, including the 2015 BMW Alpina B7L xDrive, 2015 BMW Alpina B7 xDrive, 2015 BMW 750i xDrive, 2015 BMW 750i, and 2015 BMW 750Li xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary work:

Remove right INJECTION PIPE .
Remove THROTTLE VALVE .
Release screws on intake plenum from above without fail before lowering front axle.
Secure ENGINE in installation position.
Lower front axle, releasing screws on engine mount first.
RELEASING A/C COMPRESSOR AND PLACE TO ONE SIDE .

Detach engine ventilation hose (1).

Disconnect connector.

Unscrew nuts (2).

Tightening torque: 11 61 1 AZ .

Fig 1: Identifying Engine Ventilation Hose And Nuts

Courtesy of BMW OF NORTH AMERICA, INC.

Remove THROTTLE VALVE (2).

Release screw (1).

Tightening torque: 11 61 2 AZ .

Feed out intake plenum towards rear.

Installation note:

Replace all profile seals.

Fig 2: Identifying Throttle Valve And Screw

Courtesy of BMW OF NORTH AMERICA, INC.

Assemble engine and vehicle.

Check air intake system for leaks.
