63 31 023 Removing and installing/replacing footwell light (on storage compartment at rear)

Special tools required:

• 00 9 340

Lever out footwell light (1) with special tool 00 9 340 in direction of arrow.

Disconnect plug connection and remove footwell light (1).

Replacement

• If necessary, remove BULB .
• Note BULB TYPE .
  Fig 1: Pulling Out Lever Footwell Light

  Courtesy of BMW OF NORTH AMERICA, INC.
