51 32 420 Removing and installing/replacing trim on front door window frame, left or right

Necessary preliminary tasks:

E83 only:

• Remove window cavity cover strip on outside of front door

Partially detach rubber window seal (1) at rear.

Fig 1: Detaching Rubber Window Seal At Rear

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Remove finisher (2) and press approx. 3 mm towards rear.

Fig 2: Identifying Screws And Finisher

Courtesy of BMW OF NORTH AMERICA, INC.

Remove trim (1) towards top.

Fig 3: Removing Trim Towards Top

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Following parts must not be damaged or missing:

Fig 4: Identifying Plastic Nuts, Sound Insulation And Seal

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Check trim (1) for damage, replace if necessary.

Fig 5: Identifying Trim

Courtesy of BMW OF NORTH AMERICA, INC.
