51 21 233 Removing and installing/replacing Bowden cable for outside door handle on left or right front door

WARNING: This page is about a different variant/trim than selected.

Necessary preliminary tasks:

Release Bowden cable (1) from door lock (2).

Installation:

Bowden cable (1) must be correctly engaged in locators in door lock (2).

Bowden cable (1) must be laid without kinks in bend to door lock (2).

IMPORTANT: Door cannot be opened if Bowden cable (1) is incorrectly laid.

Fig 1: Releasing Bowden Cable From Door Lock

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Outside door handle shown removed for purposes of clarity.

If necessary, release cable strap (1).

Feed Bowden cable (2) out of carrier (3).

Fig 2: Releasing Cable Strap Feed Bowden Cable Out Of Carrier

Courtesy of BMW OF NORTH AMERICA, INC.
