11 37 035 Removing And Installing/Replacing Left Eccentric Shaft Sensor (N73)

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2006 BMW 760i, 2006 BMW 760Li, 2005 BMW 760i, 2005 BMW 760Li, and 2004 BMW 760i. However, it is still accessible from the selected car via links, so may be relevant.

(Cylinder bank 7 to 12)

Necessary Preliminary Tasks:

Read out DME fault memory.
Remove left cylinder head cover. Refer to 11 12 005 REMOVING AND INSTALLING/SEALING LEFT CYLINDER HEAD COVER (N73) .

NOTE: Illustrations show N62.

Unfasten screws.

Remove eccentric shaft sensor (1).

Tightening torque, refer to 11 37 1AZ in ENGINE - TIGHTENING TORQUES .

Fig 1: Identifying Eccentric Shaft Sensor (Left)

Courtesy of BMW OF NORTH AMERICA, INC.

Assemble engine.

Check function of DME.
