Instrument Panel Air Ducts
WARNING: This page is about a different variant/trim than selected.
- Sunlight Photo Sensor -G107-
- Removing and Installing. Refer to Sunlight Photo Sensor -G107-, REMOVING AND INSTALLING or Humidity Sensor -G355-, Rain/Light Recognition Sensor -G397-, AND Sunlight Photo Sensor -G107-, REMOVING AND INSTALLING .
- Depending on the version, the Sunlight Photo Sensor -G107- may also be integrated in the Rain/Light Recognition Sensor -G397-
- Defroster Vent Cover Grille
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Defroster Vent/Windshield
- Air duct to windshield
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- If the intermediate piece for air routing/defrost -Item ) Air ducts in Vehicle - List Item: Air Duct/Defrost Intermediate Piece was crushed or crumpled when the instrument panel was installed, the air routed to the windshield will be uneven or insufficient.
- The illustration shows the A4 and A5 on the Q5 it is a separate component
- Vent to Right Front Door (Front Passenger Doors)
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Instrument Panel
- With air guides to the defroster vents and various instrument panel vents
- There are different versions.
- Removing and installing. Refer to INSTRUMENT PANEL, REMOVING AND INSTALLING .
- Wide Vent with Different Vents
- There are different versions. Refer to the Parts Information for the allocation.
- Installed depending on vehicle equipment and construction type
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Air Duct /Instrument Panel
- With the air ducts to the defroster vents and various instrument panel vents to the windshield and the side window.
- There are different versions.
- The air duct is a component of the instrument panel -Item ) Air ducts in Vehicle - List Item: Instrument Panel and cannot be replaced separately. Refer to INSTRUMENT PANEL, REMOVING AND INSTALLING .
- Air Duct with Vent for Driver Side Defroster Vent
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Right Instrument Panel Vent
- There are different versions.
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Wide Vent
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- On vehicles with a "Low" A/C system (or without an A/C system) the vent for the wide vent does not function. The vent is closed from behind with a closure cap.
- The wide vent is not available on the Q5
- Right Center Instrument Panel Vent
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Left Center Instrument Panel Vent
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Left Instrument Panel Vent
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
- Vent to Left Front Door (Driver Side Doors)
- Removing and Installing. Refer to OVERVIEW - INSTRUMENT PANEL .
