Right Engine Mount, Removing And Installing: Removing

-- Support the engine in the installation position (refer to ENGINE, SUPPORTING IN INSTALLATION POSITION ) and pretension it with the Engine Support Bridge - Spindle:10-222A/11  until the pressure on the engine mount is released.

-- Remove the front noise insulation. Refer to OVERVIEW - NOISE INSULATION .

-- Remove the front wheel spoiler and the front right wheel housing liner front section. Refer to OVERVIEW - FRONT WHEEL HOUSING LINER .

Vehicles without High-Voltage System:

-- Remove the generator or the starter generator. Refer to GENERATOR, REMOVING AND INSTALLING .

Continuation for All Vehicles:

Fig 1: Left/Right Electrohydraulic Engine Mount Solenoid Valve -N144- / -N145- Component Location

Courtesy of AUDI

-- Release and disconnect the connector -arrow- for the Right Electrohydraulic Engine Mount Solenoid Valve -N145-. (Left shown.)

-- Free up the electrical wire.

-- Remove the bolts -arrows- and the right engine support mount -1-.

Courtesy of AUDI

-- Remove the bolts -arrows- for the engine mount -1-.

Courtesy of AUDI

-- Lift the engine using the Engine Support Bridge - Spindle:10-222A/11  -1- on the correct side to dimension -a-.

Fig 2: Identifying Engine Support Bridge - Spindle 10 - 222 A /11

Courtesy of AUDI

• Dimension -a- = approximately 20 mm.

-- Remove the engine mount, at the same time disconnect the connector -1- for the Assembly Mount Sensor 1 -G748- (example illustration).

Fig 3: Assembly Mounts Sensor Component Location

Courtesy of AUDI
