Overview - Rear Lid Release
WARNING: This page is about a different variant/trim than selected.
- Cable
- For the emergency release
- Removing and Installing. Refer to Emergency release cable on the latch, removing and installing: .
- Coupling
- For the emergency release cable
- Clip
- For the emergency release cable
- Quantity: 4
- Handle
- For the emergency release cable
- Emergency Release Cable
- From the vehicle interior
- Removing and Installing. Refer to Emergency release cable in the vehicle interior, removing and installing: .
- Rear Lid
- Grommet
- In the rear lid
- Mount
- To guide the emergency release cable on the hinge
- Grommet
- In the body
- Mount
- To guide the emergency release cable in the rear lid
- Latch
- Removing and Installing. Refer to LATCH, REMOVING AND INSTALLING, ROADSTER .
- Nut
- 21 Nm
- Quantity: 2
