Front Center Defroster Vent, Removing And Installing: Removing
WARNING: This page is about a different variant/trim than selected.
-- Remove the speaker trim. Refer to SPEAKER TRIM, REMOVING AND INSTALLING .
-- If equipped: remove the sunlight photo sensor. Refer to SUNLIGHT PHOTO SENSOR -G107-, REMOVING AND INSTALLING .
-- If equipped, remove the treble speaker. Refer to COMPONENT LOCATION OVERVIEW - SOUND SYSTEM .
-- Release the clip -1- with the : T10383/1 in direction of -arrows- and remove the defroster vent -2- toward the rear.
