Overview - Head Curtain Airbag
WARNING: This page is about a different variant/trim than selected.
- Bolt
- 6.5 Nm
- Replace after removing
- Connector
- Driver side: for Driver Head Curtain Airbag Igniter -N251-
- Front passenger side: for the Front Passenger Head Curtain Airbag Igniter -N252-
- Disconnecting and connecting. Refer to Removing - Pull out connector lock -2- in direction of -arrow- and disconnect the connector -1-. .
- Head Curtain Airbag
- Driver side: with Driver Head Curtain Airbag Igniter -N251-
- Front passenger side: with Front Passenger Head Curtain Airbag Igniter -N252-WARNING:
Follow all safety precautions when working on pyrotechnic components. Refer to SAFETY PRECAUTIONS FOR PYROTECHNIC COMPONENTS .
- Removing and installing. Refer to HEAD CURTAIN AIRBAG WITH IGNITER, REMOVING AND INSTALLING .
- Clip
- Quantity: 4
- Bolt
- 6.5 Nm
- Replace after removing
- Black Line
- Serves as anti-rotation protector
- Must be visible after assembly.
