Fastener Tightening Specifications

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 Audi S7, 2015 Audi RS 7, 2015 Audi A7 Quattro, 2014 Audi S7, and 2014 Audi RS 7. However, it is still accessible from the selected car via links, so may be relevant.

Component	Fastener Size	Nm
Anti-Theft Immobilizer Reading Coil Mount	-	3
Headlamp Housing Mount	-	4.5
HID Headlamps
Power Output Stages	-	1.5
Housing¹	-	4.5
Housing²	-	6
Range Control Positioning Motor	-	2
Range Control Positioning Motor Housing Cover	-	2
LED Headlamps
Power Output Stages	-	1.5
Housing	-	4.5
Housing	-	6
Headlamp Fan	-	1.5
Headlamp Fan 2	-	2
Headlamp Fan Housing Cover	-	2
LED Inner Taillamp
Inner Tail Lamp Housing, Nut	-	2
Inner Tail Lamp Housing, Screw	-	4
Inner Tail Lamp Housing Cover	-	2
LED Outer Taillamp
Back-Up Lamp	-	2
Back-Up Lamp Cover	-	2
Housing	-	3.5
¹ For bolt tightening clarification, refer to Part 1 - Headlamp Housing, Bulbs, Control Modules and see items -7, 8- ² For bolt tightening clarification, refer to Part 1 - Headlamp Housing, Bulbs, Control Modules and see items -15-

Tightening Specification and Sequence: High-Mounted Brake Lamp Bulb

Fig 1: Tightening Specification and Sequence Of High-Mounted Brake Lamp Bulb

Courtesy of AUDI OF AMERICA, LLC

-- Tighten the nut to 2.5 Nm in the following sequence: -1 to 5-.
