Subwoofer - R211-, REMOVING AND INSTALLING
WARNING: This page is about a different car, the 2015 Audi A7 Quattro and 2014 Audi A7 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
The Subwoofer - R211- - 2- is located in the right luggage compartment recess.
Removing
-- Turn off the ignition and all electrical consumers and remove the ignition key.
-- Remove the luggage compartment floor.
-- Remove the screws and nuts - arrows- on the Subwoofer - R211- - 1-.
-- Release and disconnect the connector - 2- from the Subwoofer - R211- - 1-.
-- Remove the Subwoofer - R211- - 1- upward.
Installing
-- Install in reverse order of removal.
Tightening Specifications
