Overview - Hood
WARNING: This page is about a different variant/trim than selected.
- Hood
- Removed pedestrian protection: reset the hinge. Refer to HINGE, RESETTING
- Removing and installing. Refer to HOOD, REMOVING AND INSTALLING
- Hook
- Removing and installing. Refer to HOOK, REMOVING AND INSTALLING
- Cap Nut
- 8 Nm
- Cap Nut
- 8 Nm
- Striker
- Removing and installing. Refer to STRIKER, REMOVING AND INSTALLING
- Screws
- 11 Nm
- Catch bracket
- Removing and installing. Refer to RELEASE CABLE, REMOVING AND INSTALLING
- Ball Pin
- Gas-Filled Strut
- Removing and installing. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING. .
- Install with tube end of strut at body.
- Pedestrian Protection Trigger 1 -G598-
- Removing and installing. Refer to HINGES, REMOVING AND INSTALLING, WITH PEDESTRIAN PROTECTION
- Nut
- 8 Nm
- Hinge (Active)
- Removing and installing. Refer to HINGES, REMOVING AND INSTALLING
- Nut
- 25 Nm
- Hinge (Passive)
- Removing and installing. Refer to HINGES, REMOVING AND INSTALLING
