Front Seat, Removing And Installing, Manual: Removing

WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2016 Audi S4, 2016 Audi A4 Quattro, 2016 Audi A4, 2015 Audi S4, and 2015 Audi A4 Quattro. However, it is still accessible from the selected car via links, so may be relevant.

WARNING:

Follow all Safety Precautions when working with pyrotechnic components. Refer to SAFETY PRECAUTIONS .

-- Turn on the ignition.

-- Disconnect the battery ground cable with the ignition turned on. Refer to WORKING ON THE AIRBAG SYSTEM .

-- Remove the front belt end fitting. Refer to FRONT BELT END FITTING, REMOVING AND INSTALLING .

-- Bring headrest into lowest lock position.

Fig 1: Pressing Seat Forward/Back Adjustment Handle

Courtesy of AUDI OF AMERICA, LLC

-- Press the seat forward/backward handle and move the seat -2- as far back as possible.

WARNING:

Before handling pyrotechnic components (for example, disconnecting the connector), the person handling it must "discharge static electricity". This can be done by touching the door striker, for example.

-- Disconnect the connectors at the connector station in the floor panel. Refer to CONNECTORS, DISCONNECTING AND CONNECTING .

-- Connect the Airbag Lockout AdapterVAS6281. Refer to AIRBAG ADAPTER, CONNECTING AND DISCONNECTING .

-- Remove the front bolts -1- (quantity 2) from the console -4-.

-- Press the seat forward/back adjustment handle and move the seat -2- as far forward as possible.

Fig 2: Pressing Seat Forward/Back Adjustment Handle

Courtesy of AUDI OF AMERICA, LLC

-- Remove the rear bolts -1- (quantity 2) from the bracket -3-.

-- With help from a second technician, lift the seat -2- out of the vehicle.
