Sill Side Retaining Bracket Trim

Removing

-- Remove tunnel side trim panel:

• Manual front seat, refer to SILL SIDETRIM
• Power front seat, refer to SILL SIDE TRIM .

-- Remove the bolt -4-.

Fig 1: Identifying Sill Side Retaining Bracket Trim Components

Courtesy of AUDI OF AMERICA, LLC

-- Remove bolts -3- (quantity: 2).

-- Remove the bracket -2- from the front seat -1-.

Installation

Install in reverse order of removal.
