Seat Frame

Special tools and workshop equipment required

• Upholstery clip pliers V.A.G 1634
  Fig 1: Identifying Upholstery Clip Pliers V.A.G 1634

  Courtesy of AUDI OF AMERICA, LLC

Removing

Fig 2: Identifying Seat Bench, Removal

Courtesy of AUDI OF AMERICA, LLC

-- Remove the seat bench. Refer to BENCH SEAT .

-- Cut the upholstery clips -2-.

-- Remove cover with upholstery -1- from seat frame -2-.

Installation

Install in reverse order of removal. Note the following:

-- Use new upholstery clips.

-- Close wire clips with upholstery clip pliersV.A.G 1634.

-- Place the upholstery clips in their original locations.
