OVERVIEW - Auxiliary Fuel Pump - V393-
WARNING: This page is about a different variant/trim than selected.
Vehicles with Engine Code CATA through 05/2010, CCMA through 05/2010, CASA, CASB
- Connector
- Nut
- 9 Nm
- Bracket
- For the Auxiliary Fuel Pump - V393-
- Rubber Bracket
- Installed with the nubs into the bracket -3-
- Fuel Hose
- Auxiliary Fuel Pump -V393-
- Fuel delivery, checking, refer to Auxiliary Fuel Pump - V393-, CHECKING DELIVERY RATE .
- Removing and installing, refer to Auxiliary Fuel Pump - V393-, REMOVING AND INSTALLING .
- Rubber Bracket
- Installed with the nubs into the bracket -3-
- Fuel Hose
- To fuel filter
