Electrical/electronic components and installed locations

WARNING: This page is about a different variant/trim than selected.

Data Link Connector (DLC)

Fig 1: Data Link Connector (DLC)

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: The Data Link Connector (DLC) for Vehicle Diagnosis, Testing and Information System VAS 5051 is located in drivers side foot well.

The following listed components can be tested in "Guided Fault Finding" with vehicle diagnostic, testing and information system VAS 5051.

Shift lock solenoid N110

Fig 2: Shift Lock Solenoid N110

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: The selector lever lock solenoid is located in the shift mechanism and can only be replaced together with the shift mechanism function unit → Shift mechanism function unit, manual release, assembly overview .

Mechatronics unit, Transmission Control Module (TCM) J217 , Multi-Function Transmission Range (TR) Switch F125 , Transmission Input Speed (RPM) Sensor G182 and Transmission Output Speed (RPM) Sensor G195

Fig 3: Mechatronics Unit, Transmission Control Module J217 , Multi-Function Transmission Range Switch F125 , Sensor For Transmission RPM G182 And Sender For Transmission Output RPM G195

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: The mechatronics unit is bolted to underside of transmission housing and is covered by transmission oil pan.

The mechatronics unit incorporates the hydraulic control, Transmission Control Module (TCM), Multi-Function Transmission Range (TR) Switch and the sensors and actuators as a complete synchronized unit. Included are:

Transmission Control Module (TCM) J217
Multi-Function Transmission Range (TR) Switch F125
Transmission Input Speed (RPM) Sensor G182
Transmission Output Speed (RPM) Sensor G195

The "Mechatronics" unit can only be replaced as a complete unit.

NOTE:

All components mentioned are tested by On Board Diagnostics (OBD).

Mechatronics unit, removing and installing → Mechatronics unit, removing and installing .

Internal transmission wiring harness

Fig 4: Locating Wiring Harness With Connector Is Attached To Mechatronics Unit

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: The wiring harness - A - with connector - C - is attached to the mechatronics unit - B -.

Removing and installing wiring harness → Wiring harness in transmission, removing and installing .

Transmission Range (TR) Display Y6

Fig 5: Transmission Range (TR) Selector Lever Display -Y6-

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: Integrated into instrument cluster

NOTE:

Transmission Range (TR) Display Y6 can only be replaced as a set with the instrument cluster.

Kick Down Switch F8

Fig 6: Kick Down Switch F8

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: Kick Down Switch F8 is located on vehicle floor.

NOTE:

Kick Down Switch F8 is tested by On Board Diagnostics (OBD).

Kick Down Switch F8 , removing and installing → 20 - FUEL SUPPLY .

Tiptronic Switch F189

Fig 7: Circuit Board & Retaining Tabs

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: Tiptronic Switch F189 is integrated into circuit board of symbol insert, which is located in shift mechanism cover.

Tiptronic switch F189 , removing and installing → Shift mechanism function unit, manual release, assembly overview .

Coolant Cut-off Valve N82

Fig 8: Coolant Cut-Off Valve N82

Courtesy of VOLKSWAGEN UNITED STATES, INC.

Location: Coolant Cut-off Valve N82 - 1 - is installed under transmission, next to ATF cooler.
