Adaptation channel 62-Adaptation for information data-BUS: Notes

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Adaptation Channel 62, Adaptation For Information Data-BUS (1 Of 2)

Courtesy of AUDI OF AMERICA, INC.

Select function "62" in button field -2- for "Adaptation channel 62" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Adaptation Channel 62, Adaptation For Information Data-BUS (2 Of 2)

Courtesy of AUDI OF AMERICA, INC.

Channel 62
read and test

No indication
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value

NOTE:

The adaptation values of the table must be entered. See M.Y. 2001 or From M.Y. 2002 .
When replacing instrument cluster, observe. See Input values for replacing instrument cluster .

Installed control modules (addition of corresponding adaptation values) that participate in the A6 Comfort system CAN-bus are added (See measuring value block. See Measuring value block 140 ).
