Cruise control system, activating: Procedure

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Cruise Control System, Activating (1 Of 5)

G02720694

Courtesy of AUDI OF AMERICA, INC.

Press selection -1- of vehicle system "01 - Engine electronics".
Wait until the next indication appears on display.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Cruise Control System, Activating (2 Of 5)

G02720695

Courtesy of AUDI OF AMERICA, INC.

Control module identification of Engine Control Module (ECM).
Control module identification of immobilizer

Click on --> button

Display on VAS 5051:

Fig 3: Display On VAS 5051 - Cruise Control System, Activating (3 Of 5)

G02720696

Courtesy of AUDI OF AMERICA, INC.

In selection -1-, select the diagnostic function "11 - Login-procedure".

Display on VAS 5051:

Fig 4: Display On VAS 5051 - Cruise Control System, Activating (4 Of 5)

G02720697

Courtesy of AUDI OF AMERICA, INC.

Enter code word Max. input value = 65535

Select code number 11463 in button field -2- and press Q button to confirm input.

Display on VAS 5051:

Fig 5: Display On VAS 5051 - Cruise Control System, Activating (5 Of 5)

G02720698

Courtesy of AUDI OF AMERICA, INC.

Select diagnostic function "06 - End Output" in selection -1-.
