Login Procedure, instrument cluster
WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.
Display on VAS 5051:
- Press selection -1- of vehicle system "17-instrument cluster"
- Wait until the next indication appears on display.
Display on VAS 5051:
- Control module identification of the instrument cluster
- Control module identification of immobilizer
- Click on --> button
Display on VAS 5051:
- In selection -1-, select the diagnostic function "11 - Login-procedure".
Display on VAS 5051:
- Enter code word Max. input value = 65535
- Enter previously determined 7-digit PIN (of instrument cluster) in button field -2-.
- Press -Q- button to confirm input.
NOTE:
- After the third incorrect input of the 7-digit PIN, the control module for anti-theft immobilizer or Engine Control Module (ECM) will be locked.
- It is not possible to make another attempt for 10 minutes. During this time, the ignition must remain constantly switched on. On Board Diagnostic (OBD) must be exited using the "End Output" function 06. This time is doubled after every third consecutive incorrect attempt, up to a maximum of 255 minutes.
Display on VAS 5051:
NOTE:
Once the login procedure has been successfully completed, the warning lamp will light constantly and the immobilizer will be switched free:
- as long as the engine is running and the ignition key remains inserted,
- for 45 minutes, as long as the ignition key remains inserted (engine not running),
- for 5 minutes, if ignition key is removed.
NOTE:
If indication -1- appears in display field: "Function unknown or cannot be performed at this moment", the 7-digit PIN was entered incorrectly (e.g. incorrect secret code)
